LODHA Lab Ampoule Filling and Sealing Machine

Automatic Ampoule Filling and Sealing Machine Model: LI-AFS is used for filling and sealing of glass ampoules. Machine is widely using in pharmaceutical, biotech, cosmetic, veterinary & chemical industry. We design Ampoule Filling and Sealing Machine as per our standard model as well as custom made models according to customer’s specific requirements.

Machine built on principal of slant travel of ampoules while filling and sealing to take care wide variation of ampoule neck dimensions, thicknesses and ovality of available ampoules. Ampoule Filling and Sealing Machine is built on Stainless Steel square pipes frame & totally encompassed with Stainless Steel coverings in pleasing matt finish design. Large opening area configured on bottom side of the machine for absolute cleaning and maintenance of the machine. The pendant type electrical control panel is lifted from machine for ease of operation and safety.

We are having machines to fill open mouth ampoules as well as closed mouth ampoules.

Salient Features:

Compact GMP model Production output ranging from 30 ampoules/minute to 150 ampoules/minute All contact parts made from AISI SS 316L & other non-contact parts made from AISI SS 304. Machine is suitable to fill 1ml to 20ml ampoules and minimum change over parts from 1ml to 20ml ampoule size “No Ampoule – No Filling” system Ampoule neck centring during gas flushing and filling operations Possibility of nitrogen gas flushing before, during and after filling Full accessibility allows easy maintenance Machine equipped with pre-warming station Minimum change over time, little maintenance & easy cleaning

Process Operation:

The sterilized ampoule tray directly loaded in to slant hopper of the unit. The Synchronized star wheel delivers ampoules one by one on moving eccentric ampoule rack in single/two/four/six. During the stoppage of rack sequentially pre-gassing, filling, post gassing, pre heating and final sealing is achieved. Duly filled sealed ampoules then collected on collection tray automatically without hand touch.
